Description
Ball Valve Curb Stop for Copper and CTS Poly Water Service
Product Overview
Every water service needs a shutoff that crews can reach without digging. That is the job of a curb stop valve: it sits on the buried service line under a curb box and closes with a curb key from ground level. The Cambridge Brass 202NL uses a full-port brass ball and compression ends for copper or CTS poly, in 3/4" to 2".
Inside the 202NL Curb Stop
- Full-port ball: the open valve leaves flow unrestricted, so the shutoff doesn't narrow the service line.
- Quarter-turn head: a 90° operating head takes the valve from fully open to fully closed with low turning effort.
- Shuts off both ways: it seals from either direction and is rated for 300 PSI working pressure.
- Sealed stem: a blowout-proof stainless steel stem with double O-rings keeps line pressure away from the operating head.
- Grip at each end: an EPDM compression seal with an embedded stainless steel gripper ring seals the pipe and resists pull-out.
- Copper contact: a brass conductivity spring moulded into each seal gives electrical contact with copper tubing.
How a Curb Stop Valve Works
Picture the service line running from the water main to the building. The curb stop sits on that line underground, and a curb box rises above it to ground level. To stop the water, lower a curb key down the curb box, fit it on the operating head, and give it a quarter turn.
CTS Size and Fit Chart
Pick the brass curb stop valve size by the pipe's outside diameter (OD), not its nominal size, so measure the OD first. Both ends are the same size. Copper type K or L tubing and CTS poly pipe rated SDR-9 share these ODs, so this copper curb stop fits either one. CTS and IPS fittings are not interchangeable: PVC and IPS poly pipe are larger and need the IPS compression curb stop.
| Nominal Size | Actual CTS OD (measure this) | Valve Length | Valve Height | Approx. Weight |
|---|---|---|---|---|
| 3/4" | 0.875" | 3.75" | 2.50" | 2.5 lb |
| 1" | 1.125" | 4.42" | 2.68" | 3.9 lb |
| 1-1/4" | 1.375" | 6.56" | 3.31" | 9.8 lb |
| 1-1/2" | 1.625" | 6.56" | 3.31" | 9.3 lb |
| 2" | 2.125" | 6.83" | 3.61" | 12.5 lb |
Putting It in the Ground
These points come from the Cambridge Brass instructions for compression ends and curb stops.
- Make a square, clean cut with a tube cutter, not a hacksaw, and slide a stainless steel CTS insert stiffener into the plastic pipe.
- Push the pipe all the way in, then tighten until the nut bottoms against the body shoulder.
- Put the wrench on the flats only, and hold the valve body with a second wrench.
- Pressure test before backfilling, then backfill and compact the soil with care.
Specifications
| Specification | Details |
|---|---|
| Manufacturer | Cambridge Brass |
| Model | 202NL |
| Valve type | Ball style curb stop, full port |
| End connections | CB compression x CB compression (CTS) |
| Pipe | Copper type K or L (ASTM B88); CTS polyethylene SDR-9 (AWWA C901, ASTM D2737) |
| Working pressure | 300 PSI, bubble-tight at 300 PSIG |
| Operating head | 90° (quarter turn) |
| Body and end bodies | Cast no-lead brass, alloy C89833 |
| Ball | No-lead brass |
| Seats | PTFE (Teflon) |
| Stem | Stainless steel, blowout-proof, double O-ring sealed |
| Compression seal | EPDM, with stainless steel gripper ring and brass conductivity spring |
| Installation | Wrench flats on body and nuts |
| Standards | AWWA C800, NSF/ANSI 61-8, NSF/ANSI 372 |
| Service | Cold water service lines |
| Insert stiffener | Required on plastic pipe |
| Not for | IPS pipe, PVC pipe, hot water |
Buy Curb Stop Valves Online from Cleanflow
Order the 202NL curb stop valve from Cleanflow Utility Supply Company, an authorized Cambridge Brass supplier. Cleanflow ships across Canada and the USA; free shipping applies to most orders over $199, and exchanges are accepted within 30 days of purchase under the Cleanflow refund policy. For sizing help, email info@cleanflow.ca.
Frequently Asked Questions
What is a curb stop valve?
It is the buried shutoff on a water service line, between the water main and the building. A curb box above it lets someone reach down and close it from ground level with a curb key.
How does a curb stop valve work?
A curb key turns the operating head. In a ball valve curb stop like this one, a quarter turn swings the ball's opening across the pipe to stop the water, and turning it back lines the opening up again.
How do you turn off a curb stop valve?
Open the curb box lid, slide a curb key down onto the operating head, and turn it 90 degrees. Local rules on who may operate a curb stop vary, so check with your water utility first.
Ball valve vs curb stop: what is the difference?
They describe different things. A curb stop is the job and the location: a service line shutoff under a curb box. A ball valve is how it closes. Curb stops come in ball or plug styles, and the 202NL is a ball style.
Where is the water shut-off valve at the curb?
Look for the curb box lid at ground level along the service line route between the water main and the building. The curb stop valve sits at the bottom of that box, on the buried service line.
