Hallett™ 500PN: Advanced UV Disinfection with Crossfire Technology

The Hallett™ 500PN Potable Water UV Disinfection System utilizes UV Pure's patented Crossfire Technology to deliver superior UV disinfection. This system incorporates elliptical reflectors that redirect light energy from 360 degrees, overcoming shadowing and ensuring a sterilizing UV dose to harmful pathogens.

Key Features: Reliable and Efficient Water Disinfection

Crossfire Technology: Elliptical reflectors ensure 360-degree light redirection for maximum pathogen exposure.
Self-Cleaning Quartz Sleeve: No manual cleaning required, preventing fouling.
High Performance: Effective disinfection for up to 10x more difficult water.
Air Mounted UV Lamps: No water contact lamp changes, ensuring easy maintenance.
Dual Smart UV Sensors: Continuously monitor lamp output and water quality, reducing nuisance alarms and simplifying troubleshooting.
Built-In Temperature Management: Includes air cooling and purge valve to reduce false alarms.
Built-In Surge Protection: Protects against damage from power surges.
Colour Touch Screen Interface: Easy to use for system monitoring.
Two Dry Contacts: For warning and alarm signals.
Optional 4-20 mA Output with MODBUS Connectivity: For advanced monitoring.
Remote Start Capability: Enhances operational flexibility.
USB Plug-In Port: Allows easy data monitoring.
Optional Shut-Off Valves: Available for added convenience.
NSF/ANSI 55 CLASS A: Certified by NSF International, ensuring high standards of water disinfection

Performance Specifications

Flow Rate: Up to 16.5 US gpm (62.5 Lpm)
UV Dose: Minimum 40 mJ/cm²
UV Transmittance: Minimum 75% UVT
Water Hardness: Maximum 855 mg/L (50 gpg)
Iron Content: Maximum 3 mg/L (3 ppm)
Temperature Range: 34 - 104°F (1 - 40°C) for air and water
Water Pressure: 5 - 100 psig (34 - 690 kPa)
Relative Humidity: Maximum 70%

Built-In Features

Quartz Sleeve Cleaning: Automatic mechanical wiper
Wiper Position Switch: Built-in
Purge Valve: Built-in
Cooling: Forced air built-in
Flow Restrictor: Standard internal
Shut-off Valve: Optional automatic solenoid

Electrical and Certification

Voltage: 120 VAC/60 Hz or 230 VAC/50 Hz
Power Consumption: 196 W
Certifications: UL 979, IEC 60335-1, IEC 60335-2-109, CE
UV Lamps: Dual LPHO - air mounted, 9,000 hours typical life
Lamp Cycles: Maximum 12 per 24 hours
Sensors: Dual UV - calibrated to NIST standards
Dry Contacts: Built-in (2 provided for warning and alarm)
Interface: Colour LCD resistive touchscreen display
Alarming: Indicator light and audible alarms
Remote Start/Stop: Built-in
Onboard Diagnostics: Built-in
Output & Modbus: 4-20mA Output, optional Modbus

Physical Specifications

Dimensions (H x W x D): 36.5 x 9.6 x 8.6 in (926 x 244 x 218 mm)
Weight: Dry - 32 lb (14.6 kg), Wet - 36 lb (16.3 kg)
Wetted Parts: Meets NSF/ANSI/CAN 61 & NSF/ANSI 372 for water up to 73°F (23°C)
Body Materials: Anodized aluminum and 316 Stainless Steel
Body Configuration: Double door with side hinges
Inlet/Outlet Ports: 1" MNPT Stainless Steel, optional Stainless Steel hose
Ingress Protection Rating: IP 51, optional IP 66 for NEMA cabinet systems
Multiple Units: Multiplex manifold and cabinets available

Warranty

Structural, Hardware and Mechanical Components: 5-year limited warranty
Electrical Components and Quartz Sleeves: 3-year limited warranty
Bulbs: 12-month limited warranty
Sensor Probes: 1-year limited warranty

Benefits

Easy to Install

Plug and Play: No need to worry about space to remove the lamps, these are air mounted and are removed by opening the front of the unit.

Easy to Maintain

Non-Contact Maintenance: The air mounted lamps and sensors can be removed without the operator being in contact with potentially contaminated water.
Self-Cleaning Quartz Sleeve: The mechanical wiper means there is no need to worry about fouling or pulling out the quartz sleeve to clean it. It is also easy to inspect.

Less Annoying Alarms

Built-In Temperature Control: Prevents alarms from lamps/water overheating.
Quartz Sleeve Wiper: Reduces alarms from quartz sleeve fouling.
Air Mounted Sensors: Eliminates alarms from fouled sensors.

Easy to Monitor

Dry Contacts: Includes 2 dry contacts for easy alarm setup.
Colour Touch Screen Interface: Remembers the last 99 messages with a time stamp.
USB Port: Ideal for data loggers.
Optional 4-20mA Output & MODBUS Connectivity: Available for advanced monitoring.
