Description
High-Capacity Magnetic Filtration for Improved Efficiency and Extended System Life
Standard single-chamber filters cannot keep pace with the volume of magnetite and debris that larger hydronic heating systems produce. The ADEY MagnaClean DualXP® Magnetic Filter solves that with two powerful neodymium magnetic capture zones, a 50gpm flow rate, and four non-magnetic debris capture zones, permanently installed on the return line to intercept everything before it reaches the heat exchanger.
Order the MagnaClean DualXP Now for stronger filtration, better efficiency, and longer system life.
What the ADEY MagnaClean DualXP Does
The MagnaClean DualXP by ADEY is an in-line magnetic filter designed for large residential and light commercial hydronic systems. It uses dual neodymium magnets to capture circulating magnetite before it reaches the heat exchanger, with flow design improving contact between water and the magnetic cores. The filter is bi-directional.
Either port can serve as the inlet, which increases installation flexibility on existing pipework without requiring modifications to suit a fixed-orientation filter.
Full Technical Specifications
| Specification | Details |
|---|---|
| Filter body and lid | Glass-reinforced nylon |
| Fluid capacity | 0.64 gal / 2.43 litres (telescopic connectors retracted) |
| Flow rate | Up to 50gpm |
| Flow configuration | Bi-directional – any port can be inlet |
| Main lid seal | EPDM |
| Housing | Stainless steel |
| Length | 225 mm |
| Diameter | 19 mm |
What the DualXP Captures and Protects Against
- Black iron oxide (magnetite) - the primary cause of boiler inefficiency and heat exchanger blockage
- Non-magnetic debris including scale particles, copper oxide, and suspended solids
- Particles from 50 microns down to 5 microns (0.2 mil) per ADEY's official submittal data
- Contaminants that cause ECM pump failure, control valve blockage, and thermostat damage
- Debris that reduces heat emitter output and forces boilers to run longer and harder
Protecting large systems takes dual magnetic power. Order the MagnaClean DualXP today.
Install the Right Filter for the Size of the System
A filter rated for 150,000 BTU systems will not adequately protect a 350,000 BTU installation. The ADEY MagnaClean DualXP Magnetic Filter from Cleanflow is purpose-made for large residential and light commercial systems that need dual-chamber magnetic capture, 50gpm flow capacity, and the flexibility to install on any pipework orientation.
Order the MagnaClean DualXP online for powerful magnetite removal, improved system efficiency, reduced wear on components, and longer heating system lifespan.
Why does the DualXP need two magnetic chambers instead of one?
Larger systems circulate more water, so more debris reaches the filter. A single core saturates faster, reducing effectiveness. A second chamber adds capacity, spreads the load across two cores, and maintains filtration performance between service intervals.
How do the integral flow diverters in each port improve capture?
Each inlet and outlet port includes a flow diverter that redirects water around both magnetic chambers instead of straight through. This ensures full contact with the magnets on every pass, improving capture efficiency across a wider range of particle sizes.
What does the ultra-thin removable sleeve do during servicing?
A thin plastic sleeve covers the magnetic core in each chamber. During servicing, sliding the sleeve off removes captured debris cleanly. It prevents re-dispersion, keeping the magnet clean and ready for reinstallation without direct contact with sludge.
Can the DualXP be used on glycol-filled systems?
Yes. The MagnaClean DualXP supports glycol solutions up to 50 percent concentration. EPDM seals provide compatibility with inhibitors and glycol. This makes the filter suitable for frost protected systems and light commercial chiller loops using antifreeze in system water.
How does direct chemical dosing through the filter chambers work?
Both magnetic chambers include access points for adding ADEY chemicals such as MC1+ Protector during servicing. As the filter is reassembled and valves reopen, chemicals enter system water, removing the need to dose through radiators or filling loops.
Where exactly should the DualXP be positioned on the circuit?
ADEY recommends installing the filter on the system return, after the last radiator and before the boiler. This position captures debris before it reaches the heat exchanger. Isolation valves on both sides allow servicing without draining the entire system.
