Description
Outdoor Rated Inline Booster Pressure Tank for Irrigation and Shallow Well Systems
Product Overview
The Flexcon PJR15 Jet-Rite 2 is a compact 4.8-gallon inline pressure tank designed to stabilize system pressure and reduce pump cycling. It is commonly installed with booster pumps, irrigation systems, shallow well jet pumps, and centrifugal pump setups.
Quick Specs
- Capacity: 4.8 Gallons
- Maximum Pressure: 125 PSI
- Connection Size: 3/4" NPT Stainless Steel
- Pre-Charge: 28 PSI
- Certification: NSF/ANSI 61 certified for potable water systems
Key Features of Flexcon PJR15 Jet-Rite 2 Pressure Tank
- The tank uses a 100% butyl rubber diaphragm to separate air and water and maintain consistent pressure.
- A copolymer polypropylene liner isolates the water from the steel shell to maintain purity.
- The 16-gauge cold-rolled steel shell receives an appliance-quality powder coat finish for outdoor durability.
- A condensation-reducing profile virtually eliminates external corrosion on the tank body.
- The reinforced 3/4" stainless steel system connection stands up to harsh environmental elements.
- The brass air valve features a tight O-ring seal to prevent air loss over time.
Installation Components (Sold Separately)
Recommended Accessory for New Installations
This product includes the inline pressure tank only. Additional system components, such as pressure switches, transducers, sensors, and fittings, must be selected separately based on your system requirements.
Wall Mount Pressure Tank Manifold Kit – Build a complete pressure tank system with pre-plumbed, easy-install manifolds designed for professional performance.
Fully equipped kit includes:
- Stainless Steel Sediment Tap / Hose Bib (3/4")
- Stainless Steel Pressure Relief Valve (3/4")
- Stainless Steel Liquid Filled Pressure Gauge (2.5")
- Teflon Tape (for stainless steel fittings)
- Wall Mounting Kit with steel “L” brackets, lag screws, U-bolts, nylon nuts & end caps
Flexcon PJR15 Specifications
| Category | Details |
|---|---|
| Model | PJR-15 |
| Total Volume | 4.8 gallons (18 liters) |
| Maximum Working Pressure | 125 PSI |
| Precharge Pressure | 28 PSI |
| Total Weight | 10.0 lbs (4.6 kg) |
| 20/40 Switch Drawdown | 1.7 gal (6.4 liters) |
| 30/50 Switch Drawdown | 1.5 gal (5.7 liters) |
| 40/60 Switch Drawdown | 1.3 gal (4.9 liters) |
Dimensions
- (A) Height (in): 14.5"
- (B) Diameter (in): 11.0"
- (C) Connection: 3/4" NPT
Recommended Uses
- Residential water booster systems
- Irrigation pressure tank setups
- Shallow well jet pump configurations
- Centrifugal pump systems
- Light commercial constant-pressure setups
- Small inline pressure tank for shallow well jet pumps
Signs Your System Needs an Inline Pressure Tank
Your water system may benefit from an inline pressure tank if you notice any of the following issues:
- Booster pumps are turning on and off too frequently
- Inconsistent water pressure at fixtures
- Pressure drops when multiple fixtures or appliances run
- Irrigation pumps cycle rapidly during operation
- Pump motors are overheating due to short cycling
Installing a compact inline pressure tank helps stabilize system pressure and reduce excessive pump cycling.
Common Pressure System Problems
If You're Experiencing:
- Pump turning on and off too frequently
- Low or inconsistent water pressure
- Pressure drops while using multiple fixtures
- Premature pump failure or overheating
- Air sputtering from faucets
This booster pump pressure tank stabilizes system pressure, reduces pump cycling, and helps extend the lifespan of your well pump and water system.
Key Benefits of this Inline Pressure Tank
- Corrosion-resistant steel construction with durable powder coat finish
- FDA-approved water chamber materials for cleaner water storage
- Stainless steel water connection for maximum leak resistance
- Pre-charged to 28 PSI for easier and faster installation
- Reduces electricity use and minimizes pump wear
Installation & Maintenance
Installation Setup:
- Factory pre-charged to 28 PSI (adjustable)
- Compatible with 20/40, 30/50, and 40/60 pressure switch settings
- Works seamlessly with booster pumps and wall-mount tank manifold kits
Maintenance Guidelines:
- Check air pressure annually
- Maintain pre-charge exactly 2 PSI below the cut-in setting
- Monitor the system for signs of waterlogging or pressure loss
Recommended Accessories
Complete your Flexcon PJR15 inline pressure tank installation with reliable plumbing hardware. Browse pressure tank accessories like gauges and valves. Use stainless steel fittings and valves for high-pressure durability, or select bronze pipe fittings and nipples for potable water systems.
Order Your Flexcon PJR15 from Cleanflow
The Flexcon PJR15 Jet-Rite 2 pressure tank is available through Cleanflow, your trusted supplier of water infrastructure components. We provide fast shipping and distribution across Canada and the USA. Order this NSF-certified Flexcon water pressure tank directly from us to receive genuine parts backed by a 5-year warranty.
Frequently Asked Questions
Is a pressure switch included with this tank or manifold kit?
No. Pressure switches are not included and must be selected separately based on your system requirements.
Does the tank come pre-charged?
Yes, this inline pressure tank comes factory pre-charged to 28 PSI. You must adjust this air pressure to suit your system's specific operating requirements before starting the pump.
How should the tank pre-charge be set?
You must set the tank's air pre-charge exactly 2 PSI below your pressure switch's cut-in setting. You must perform this adjustment while the tank is completely empty of water.
Where should an inline pressure tank be installed?
An inline pressure tank like the Flexcon PJR15 is typically installed on the discharge side of the pump, between the pump and the system piping. It can be mounted vertically using a wall-mount bracket or installed directly on the line, depending on your system configuration. Proper placement helps stabilize pressure and reduce rapid pump cycling.
What is the difference between total volume and drawdown?
Total volume refers to the physical space inside the tank (4.8 gallons). Drawdown represents the actual amount of usable water the tank delivers between pump cycles. For this model, the drawdown ranges from 1.3 to 1.7 gallons, depending on your pressure switch setting.
Can I install this outdoor-rated inline booster pressure tank outside?
Yes. The tank features an appliance-quality powder coat finish and a sealed brass air valve equipped with an O-ring. These features withstand harsh weather and reduce external corrosion.
Is this tank safe for residential drinking water?
Yes, the Jet-Rite 2 pressure tank is NSF certified for drinking water. It features an FDA-approved butyl rubber diaphragm and a polypropylene liner that keeps the drawdown water pure.
What kind of connection does this tank use?
The tank features a reinforced 3/4-inch NPT stainless steel connection. This provides excellent leak resistance and stands up to harsh elements better than standard steel or plastic connections.
