Franklin FE50HH-T-30 High Head Effluent Pump – 1/2 HP, 50 GPM, 53' Shut-Off, Cast Iron, 30' Cord, 2" Discharge, 3/4" Solids

Franklin FE50HH-T-30 High Head Effluent Pump – 1/2 HP, 30' Cord, 2" Discharge

The Franklin Electric FE50HH-T-30 High Head Effluent Pump is engineered for tough, continuous-duty wastewater applications where performance and reliability are non-negotiable. With a 1/2 horsepower PSC motor, cast iron construction, and 3/4-inch solids handling capability, this submersible effluent pump is ideal for septic systems, vault applications, and high-head wastewater transfer.

Each unit undergoes full wet testing prior to shipment—ensuring that when your pump arrives, it’s already proven to deliver dependable performance under the most demanding conditions. Built with a heavy-duty epoxy-coated cast iron housing and a cast iron non-clog impeller, the FE50HH-T-30 resists abrasion, dissipates heat effectively, and operates with minimal clogging even in challenging environments.

With a 53-foot shutoff head and flow capacity of 50 gallons per minute, this automatic pump combines efficiency, durability, and ease of installation, making it the go-to choice for professionals installing or maintaining septic systems.

Key Features & Benefits

• High Head Performance – Pumps up to 50 GPM at 5' of head, with a maximum shutoff of 53'.

• Durable Cast Iron Construction – Pump body, base, and impeller built from rugged cast iron for strength and long service life.

• 3/4-Inch Solids Handling – Cloverleaf intake design and non-clog impeller allow reliable operation in effluent applications.

• Continuous Duty Rated – Energy-efficient Permanent Split Capacitor (PSC) motor with thermal overload protection for safe, nonstop operation.

• Quiet, Reliable Operation – Features both upper and lower ball bearings for smooth, long-term performance.

• Automatic Operation – Equipped with a mechanical tethered float switch for reliable hands-free use.

• Factory Wet Tested – Every pump is fully submerged and tested before leaving the factory to guarantee performance.

• Long 30-Foot Cord – Provides flexible installation options in deeper vaults and septic tanks.

• Certified Quality – cCSAus listed for safety and reliability.

• Warranty Protection – Backed by a 3-year warranty for peace of mind.

Technical Specifications

• Horsepower: 1/2 HP

• Voltage: 115V, 60 Hz, Single-Phase

• Amperage: 10 A full load, 18 A starting

• Cord Length: 30 ft

• Max Flow Rate: 50 GPM @ 5 ft head

• Shutoff Head: 53 ft

• Discharge Size: 2" FNPT

• Solids Handling: Up to 3/4"

• Max Liquid Temp: 140 °F (60 °C)

• Pump Dimensions: 10.6" length × 9.45" width × 10.5" height

• Weight: 38.7 lbs

• Construction Materials: Cast iron body, base, and impeller; stainless steel shaft; carbon/ceramic mechanical seal with nitrile elastomers

Professional-Grade Effluent Pumping

Whether you’re installing a new septic system, upgrading for higher head requirements, or maintaining an existing wastewater setup, the Franklin FE50HH-T-30 delivers unmatched durability and performance. Its high-flow cloverleaf intake design, rugged cast iron build, and proven factory testing make it a trusted choice for contractors, wastewater professionals, and system installers.
