Hydromatic WA1 10 Submersible Sump Pump, 3/10 HP, 38 GPM, 120V, Cast Iron, Wide Angle Float Switch, Oil-Filled Motor, 1-1/2" NPT Discharge, CSA Listed

Hydromatic WA1 10 Cast Iron Sump Pump with Wide Angle Float Switch

3/10 HP Cast Iron Submersible Pump for Basement Sumps and Septic Effluent

The Hydromatic WA1-10 is a premium submersible sump pump designed for effective water removal in basements, crawl spaces, sump pits, and industrial circulators. This Hydromatic WA1-10 sump pump operates automatically in residential sump pits and transfer tanks, helping keep spaces dry and protected.

At the heart of this sump pump is a state-of-the-art wide-angle float switch, providing automatic operation to maintain proper water levels. Its piggyback plug-in design allows for easy switching between automatic and manual operation when needed.

Built to last, the Hydromatic WA1-10 features a durable cast iron body, offering excellent resistance to wear and harsh conditions. The oil-filled motor delivers superior cooling performance, helping extend pump life and ensure long-term reliability.

Quick Specs

• Horsepower: 3/10 HP
• Voltage: 115 Volts
• Discharge Size: 1-1/2" NPT
• Solids Handling: 1/2"
• Cord Length: 10 ft
• Max Head: 25 ft vertical lift
• Flow Rate: 38 GPM @ 10 ft

Key Features of Hydromatic WA1 10 Submersible Sump Pump

• The robust cast iron body provides superior cooling characteristics to extend the life of the pump.
• A state-of-the-art wide-angle float switch ensures automatic and reliable water pumping operation.
• The unique piggyback plug-in arrangement allows for a simple conversion to manual operation.
• An oil-filled sump pump motor ensures excellent heat dissipation and contains automatic thermal overload protection.
• This 120V sump pump with float switch handles up to 1/2-inch solids for versatile residential applications.
• The single-row ball-bearing construction enhances the overall longevity and performance of the unit.

Hydromatic WA1 10 Sump Pump Specifications

Performance Overview

This hydromatic pump delivers a maximum output of 38 GPM at a 10-foot total dynamic head. The hydromatic sump pump provides steady flow and handles up to a 25-foot vertical lift.

Pump Performance Flow Rate vs Head

Construction & Design

Applications

• Basement sumps
• Crawl spaces
• Sump pits
• Septic tank effluent
• Industrial circulators
• Transfer tanks

Optimize Your Setup with Essential Upgrades

When installing or replacing your Hydromatic WA1-10 Cast Iron Sump Pump, consider enhancing your system with our recommended installation components. Upgrading at the time of pump replacement ensures a seamless integration and reduces the need for future system interruptions:

• Discharge Hose Kit: Designed to handle the output of the WA1-10, this sump pump discharge hose kit includes all necessary fittings, ensuring a leak-proof connection and efficient water displacement.
• Check Valves – Two Styles Available:
  • Compression Swing Check Valve: Our swing check valve offers reliable backflow prevention, crucial for maintaining the integrity of your pump's operation and preventing water return. Reduces water hammer for quieter pump operation. Easy to install compression style.
  • Flex Rubber Check Valve: Our flex rubber check valve is easy to install and provides backflow prevention.
• Sump Pump Alarm with Float Switch: Our sump pump liquid level alarm system can notify you before water overflows. Ideal for monitoring sump pit water levels when you're away or sleeping.

Compare Similar Models & Explore More Options

Need this pump with a vertical float switch instead? Try the Hydromatic VA1-10 with a piggyback-style vertical float for easier servicing.

You can also explore our full submersible sump pumps collection for more options from Hydromatic and other trusted brands, including high-capacity and automatic models.

Why Choose the Hydromatic WA1 10

The Hydromatic WA1 10 provides outstanding performance and longevity for harsh conditions. The cast iron construction and automatic thermal overload protection create a reliable solution for efficient water pumping.

Available through Cleanflow, we are a trusted Hydromatic pumps supplier. We offer extensive distribution across Canada and the USA to ensure you receive authentic equipment and compatible Sump Pump Accessories promptly.
